Nominal Size
(Width)
Part #
Wall
Thickness
Standard Spool Put-Ups
Available
Colors
Lbs/
100’
Bulk Spool
Shop Spool
28”
GRF28.0GL
.006”
150
’
25
’
Gold (GL)
8.13
• 6 Mil Thick Foil
• Reflects Radiant Heat
• Fiberglass Backing
• Distinct Checker Pattern
Surface Texture
• Continuous Operating
Temperature of 500°F
Radiant
Heat Protection Up To 750°F
The GOLD FOIL (GRF) is made from a lightweight aerospace material. This 6 mil
thick foil has a fire resistant pressure sensitive adhesive that incorporates a fiber-
glass backing for strength and tear resistance. The adhesive meets or exceeds the
FAA 12-second vertical burn requirement.
This gold reflective foil reflects up to 750°F of radiant heat and has a continuous
operating temperature of 500°F. It will break down at 850°F of continuous radiant
heat. There is up to a 70°F gradient temperature drop across the 6 mil thick foil
during normal operating temperatures. Key benefits: can easily be cut and config-
ured to each chassis style; easy to repair, install and remove since it adheres to
itself.
Applications include, but are not limited to:
fire walls, engine covers, side pods,
suspension, under trays/floors, bulk heads
and many more.
Radiant
Heat Protection Up To 1050°F
SILVER FOIL (SRF) is made from a lightweight aerospace material. This 14 mil thick
foil has a fire resistant pressure sensitive adhesive which meets or exceeds the FAA
12-second vertical burn requirement. The reflective foil is easy to install and
remove, and is extremely versatile in that it can be easily cut and formed.
The silver foil reflects at least 95% of radiant energy and provides continuous radi-
ant heat protection up to 1050°F and higher for short durations. There is a mini-
mum of 400°F gradient temperature drop across the film during normal operating
temperatures. The film is supplied in 28” wide rolls and weighs approximately
12 oz/yd
2
.
Nominal Size
(Width)
Part #
Wall
Thickness
Standard Spool Put-Ups
Available
Colors
Lbs/
100’
Bulk Spool
Shop Spool
28”
SRF28.0SV
.014”
120
’
25
’
Silver (SV)
19.44
• 14 Mil Thick Foil
• Radiant Heat
Protection
• Easy To Install
• Meets or Exceeds
the FAA 12 sec. Vertical
Burn Requirement
Silver Foil conforms and adheres
to irregular shapes.
