45 / 116
Nominal
Size
Part
#
Expansion Range
Standard Spool Put-Ups
Available
Colors
Kgs/
100m
Min.
Max.
Bulk Spool
Shop Spool
6,4mm KVN0.25YL
3,2mm 7,9mm 152,4m
15,2m
Yellow (YL)
0,45
12,7mm KVN0.50YL
6,4mm 15,9mm 76,2m
15,2m
Yellow (YL)
1,19
19,1mm KVN0.75YL
12,7mm 22,2mm 76,2m
15,2m
Yellow (YL)
1,79
25,4mm KVN1.00YL
19,1mm 31,8mm 61,0m
7,6m
Yellow (YL)
2,86
31,8mm KVN1.25YL
25,4mm 41,3mm 38,1m
7,6m
Yellow (YL)
3,57
38,1mm
50,8mm
KVN1.50YL
KVN2.00YL
31,8mm
44,5mm
50,8mm
63,5mm
30,5m
30,5m
7,6m
7,6m
Yellow (YL)
Yellow (YL)
4,32
5,36
A Unique Combination
Of Properties For
Demanding Applications
VECTRAN
®
FIBER (VEN) is a high-performance multifilament yarn spun from liquid
crystal polymer. Pound for pound Vectran
®
fiber is five times stronger than steel
and ten times stronger than aluminum, which makes it the material of choice in
demanding applications where other fibers fail to meet performance requirements.
Our product also demonstrates minimal moisture absorption, outstanding cut and
abrasion resistance, high dielectric strength, and melt temperature of 329
°
C.
Vectran
®
Fiber sleeving is used in a wide range of applications, including aero-
space, high tech research, industrial protection, marine, and medical uses.
Nominal
Size
Part
#
Wall
Thickness
Expansion Range Standard Spool Put-Ups
Available
Colors
Kgs/
100m
Min.
Max.
Bulk Spool Shop Spool
3,2mm
6,4mm
VEN0.13NT
VEN0.25NT
0,6mm
0,6mm
2,8mm
5,2mm
3,6mm
7,5mm
152,4m
152,4m
30,5m
30,5m
Natural (NT)
Natural (NT)
0,54
1,07
Vectran
®
is a registered trademark of the Kuraray Co., LTD.
Vectran's
®
molecular structure not only makes
it one of the world's strongest materials but
vectran is also invisible in MRI systems.
• Up to 20 Times
Stronger Than Steel
• Will Not Melt, Burn,
or Support Combustion
• Stays Soft, Flexible,
& Pliable Throughout
-274°F to 320°F
Stronger Than Steel,
Soft & Pliable
ARAMID FLEXO KV (KVN) is a soft, flexible sleeving that’s perfect for bundling and
protecting vulnerable components from the most extreme environmental conditions.
Aramid Flexo KV is braided from aramid fibers and has durability, pliability, and
extraordinary tensile strength. Aramid Flexo KV fibers are up to 20 times stronger
than steel fibers of equal diameter. KVN has excellent thermal stability, permitting
long-term, continuous use at temperatures as low as -170°C and as high as
160°C. Short term exposure up to 300°C can be tolerated. KVN does not melt or
support combustion. KVN sleeving provides extreme strength and durability, yet is
lightweight and easy to install.
*Please note that Aramid Flexo KV is degraded by ultraviolet light. Do not store in direct sunlight. Fluorescent lighting will cause
discoloration, but will not affect fiber mechanical properties.
