Heat Treated,

Fray-Resistant Fiberglass

Sleeving

Techflex INSULTHERM TRU-FIT (FGL) is a braided fiberglass sleeving which has

been heat treated and impregnated with an acrylic binder to reduce fraying and

dusting, and improve usability and performance. FGL is engineered for applica-

tions where temperatures as high as 1,200ºF may occur.

FGL is used as primary insulation on low voltage applications such as leads in

toasters, coffee makers, ranges, and other small appliances. FGL may also be used

as insulation and protection for small heaters and resistors that operate at high

temperatures, as well as to insulate over soldered connections when exposure to

solder melt temperatures is possible.

Insultherm Tru-Fit provides a sturdy, long lasting, and inexpensive insulation solu-

tion. It is flexible and expandable, and can easily be installed over applications with

irregular shapes and tight turns. Standard colors are Black and Natural, but other

colors are available by special order. Contact your account representative for

details.

Nominal

Size

Diameter

Part

#

Wall

Thickness

Expansion Range

Standard Spool

Put-Ups

Available

Colors

Min.

Max.

Bulk

Spool

Shop

Spool

24

22

20

18

16

14

12

11

10

9

8

7

6

5

4

3

2

1

0

3/8”

7/16”

1/2”

5/8”

3/4”

0.022”

0.027”

0.034”

0.042”

0.053”

0.066”

0.085”

0.095”

0.106”

0.118”

0.133”

0.148”

0.166”

0.186”

0.208”

0.234”

0.263”

0.294”

0.330”

0.375”

0.438”

0.500”

0.625”

0.750”

FGLG.24

FGLG.22

FGLG.20

FGLG.18

FGLG.16

FGLG.14

FGLG.12

FGLG.11

FGLG.10

FGLG.09

FGLG.08

FGLG.07

FGLG.06

FGLG.05

FGLG.04

FGLG.03

FGLG.02

FGLG.01

FGLG.00

FGL0.38

FGL0.44

FGL0.50

FGL0.63

FGL0.75

.006”

.006”

.006”

.006”

.006”

.006”

.006”

.008”

.008”

.008”

.008”

.008”

.010”

.010”

.010”

.010”

.010”

.010”

.016”

.016”

.016”

.016”

.016”

.016”

0.020”

0.025”

0.032”

0.040”

0.051”

0.064”

0.081”

0.091”

0.102”

0.114”

0.129”

0.144”

0.162”

0.182”

0.204”

0.229”

0.258”

0.289”

0.325”

0.375”

0.438”

0.500”

0.625”

0.750”

0.027”

0.032”

0.039”

0.049”

0.061”

0.072”

0.089”

0.101”

0.112”

0.124”

0.141”

0.158”

0.178”

0.198”

0.224”

0.249”

0.278”

0.311”

0.347”

0.399”

0.462”

0.524”

0.655”

0.786”

500

500

500

500

500

500

250

250

250

250

250

250

250

250

250

250

250

100

100

100

100

100

100

100

250

250

250

250

250

250

100

100

100

100

100

100

100

100

100

100

100

50

50

50

50

50

50

50

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

WH,NT,YL,RD,BL,BK

Protect component wiring leads from heat

and abrasion with Insultherm Tru-Fit for

an attractive and permanent finish.

• Rated to 464°F

• For High Temp - Low

Voltage Applications

• Cut and Abrasion

Resistant

• UL Recognized: VW-1

• Easy to Install - Cuts

with Scissors

• Excellent Low Temp

Flexibility

• Resists Most Organic

Solvents

Natural

Yellow

Black

Blue

Red

NT

YL

RD

BL

BK

WH

White

46

1-973-300-9242

www.techflex.com

EXTREME

TEMPERATURE
