73 / 116
Increased Friction On
Smooth Surfaces Minimizes
Slipping & Accidents
FLEXO NON-SKID (NSN) is a unique combination of our standard PET material
braided together with high-friction polymer filaments.
NSN is engineered primarily for wire and cable management on smooth floor,
high traffic environments such as broadcast studios where someone might inadver-
tently step on a cable snake and slip.
As long as there’s no excessive pressure on the cables protected with NSN, the
entire snake glides easily and quietly along the floor. When local pressure is
applied, such as when someone steps on the cable, the high friction material
comes in contact with the floor and reduces the possibility of the cable sliding out
from underfoot. NSN is substantially less “slippery” than our regular PET, yet pro-
vides the same level of flexibility and protection from cable wear and abrasion.
Non-Skid is ideal for smooth floor areas such
as photo, film, and TV studios where cable
snakes, high foot traffic, and low light
combine to create a slipping hazard.
Nominal
Size
Part
#
Expansion Range
Standard Spool Put-Up
Available
Colors
Lbs/
100’
Min.
Max.
Bulk Spool
Shop Spool
1/4”
3/8”
1/2”
5/8”
3/4”
1 1/4”
1 1/2”
2”
NSN0.25
NSN0.38
NSN0.50
NSN0.63
NSN0.75
NSN1.25
NSN1.50
NSN2.00
1/8”
3/16”
1/4”
3/8”
1/2”
3/4”
1”
1 1/2”
7/16”
1/2”
3/4”
1”
1 1/4”
1 3/4”
2”
3 1/2”
1,000’
500’
500’
500’
250’
200’
200’
200’
200’
125’
100’
75’
70’
50’
40’
50’
NY, SS & BK
NY, SS & BK
NY, SS & BK
NY, SS & BK
NY & BK
NY, SS & BK
NY, SS & BK
NY & BK
0.44
0.57
0.89
1.04
1.25
1.96
2.25
2.75
• Manages & Protects
Cable Bundles
• Increases Safety in
Foot Traffic Areas
• Economical and Easy
to Install
• Cut and Abrasion
Resistant
• Expands up to 150%
NY
SS
BK
Neon Yellow
Safety Stripe
Black
